Automatic Label Applicator
2、Combining manual bottle placement with automatic labeling, it delivers stable performance, high accuracy, and simple operation for small and medium production needs.
3、Compatible with various cylindrical containers including plastic bottles, glass bottles, and metal cans for multiple industries.
4、Easy installation, low maintenance, and independent operation help improve labeling efficiency while reducing labor costs.
5、Built for long-term durability with a 20-year service life and lifetime technical support.
6、China-based production facilities ensure reliable supply and quick delivery.
7、Southeast Asia warehouses provide efficient regional logistics support for global customers.
High-Performance Automatic Label Applicator for Round Bottles | Desktop Semi-Automatic Labeling Solution
Beijing Honghua Digital Equipment Co., Ltd. introduces the JT-130 Automatic Label Applicator, a desktop semi-automatic round bottle labelling system developed for producers demanding precision, speed and simplicity of use. This device has 13 technological patents and has been manufactured for 20 years so it can label items correctly to within ±1mm at up to 25 pieces per minute This machine is perfect for manufacturing lines who produce medications, cosmetics, food and beverages since it uses 240W of electricity with a power supply of 110V/220V. It's tiny (600x500x800mm), manufactured from 304 stainless steel so it will endure, fulfil cleanliness requirements and be simple to operate the way things are done today.
Core Technical Specifications
The JT-130 Automatic Label Applicator boasts strong construction and smart control systems that ensure consistent labeling performance in a range of production settings.
| Parameter | Specification |
|---|---|
| Model | JT-130 |
| Power Supply | 110V/220V, 50/60Hz, 240W |
| Labeling Speed | 0-25 pcs/min |
| Labeling Precision | ±1mm |
| Bottle Diameter Range | 40-100mm (customizable) |
| Label Size | H: 20-105mm, L: 20-250mm (customizable) |
| Label Reel Diameter | Inner: 76mm, Outer: 360mm (max) |
| Machine Dimensions | L600 × W500 × H800mm |
| Frame Material | 304 Stainless Steel + Aluminum Alloy |
| Control System | PLC with Digital Touch Panel |
| Service Life | 20 Years |
This machine handles cylindrical containers including plastic bottles, glass bottles, and metal cans, making it a versatile solution for multi-product facilities.
What Makes the Automatic Label Applicator’s Intelligent Control System Support Streamlined Operation?
PLC control system, digital touch panel, no technical skills needed, one-click parameter adjustment. Visual error alerts and simple interface design enable operator learning in a minute.
Advanced features include waste-preventing “No Bottle, No Label” logic, automatic output counting for production monitoring and instant issue diagnostic warnings. The gadget stores product presets for rapid changes in bottle size and label style without human recalibration.
This decreases operator dependency and production down time during shift changes or product changes.
Precision Labeling Mechanism
Specialised rotating bottle support system stabilises position of container during labelling. Elastic silicone rollers remove bubbles, wrinkles and edge lift for flawless label alignment every time.
Pharmaceutical and cosmetic industries demand precise label placement. It achieves ±1mm accuracy tolerance requirement. This impacts regulatory compliance, and brand perception. High torque servo control maintains a constant tension on a label avoiding skew during continuous operation.
Ultrasonic detection of liner-label boundaries enables transparent label application regardless of material clarity.
Industrial-Grade Construction & Hygiene Compliance
The frame is made of 304 stainless steel and aluminium alloy, which is resistant to rust and corrosion to fulfil basic GMP hygiene requirements. The open-frame design and smooth surfacing allow for simple cleaning between product cycles for culinary and medicinal applications.
This design is corrosion resistant and will survive several washdowns and chemical exposure in production. Anodised parts mean no oxidation, keeping the looks and performance for 20 years.
Durability reduces total cost of ownership by avoiding replacements and maintenance interruptions.
Flexible Customization & Expansion Options
Multi-direction adjustable stations compensate for bottle diameter fluctuation without the need for tool based alterations. Changeover times are reduced to less than three minutes by simply sliding adjustment knobs to change container sizes.
Optional attachments include date coding devices for manufacturing date printing, positioning fixtures for unusual containers, and integration ports for upstream vision inspection systems. The machine has a customised voltage settings (110V/220V/380V) and may be fitted with international standard PLC systems to meet regional compatibility.
The Automatic Label Applicator has an inexpensive initial investment and ultra-low failure rates that mean a fast ROI for small to medium production quantities. It needs no foundation changes for quick installation in existing facilities, and its footprint on the desktop is minimal.
Application Across Multiple Industries
Various sectors answer your labelling problems. Pharmaceutical companies benefit from GMP construction and accurate vial labelling. Cosmetics uses brand consistent lotion and serum bottles.
The equipment must be able to handle bottles prone to condensation without impairing adhesion for food and beverage operations. Good for chemical and home product companies. Corrosion-resistant hardware for cleaning chemical and solvent labelling.
Special container geometries may be produced for diameters from 40 mm up to 100 mm.
Comprehensive Technical Support & Global Service Network
Shanghai Honghua offers 12 months warranty and everlasting technical support for each product. Remote diagnostics Spare parts and on-site help safeguard your investment.
We have manufacturing facilities in China for reliable supply chain and speedy delivery, and warehouses in Southeast Asia to ease regional logistics. Professionals advise on setup, operation and optimisation.
Customs documents provided for logistics arrangements FOB (Shanghai/Ningbo), CIF & DAP.
FAQ
Q: Will the product work with transparent labels?
A: The method relies on ultrasonic sensors to detect the thickness difference between liner and label, instead of optical contrast, for foolproof identification of materials.
Q: Is this machine compatible with conveyors?
A: Height-adjustable mounting and modular I/O ports enable the device to sync with upstream and downstream devices at varying line speeds.
Q: Why do labelling wrinkles occur and how to fix?
A: Typically wrinkles are caused by differences in the speeds of label dispensing and product travel. This is solved by adjusting the servo motor encoder settings using the digital panel.
Q: What maintenance schedule should use?
A: Daily cleaning of the dispensing edge and silicone roller will prevent adhesive build-up jamming. Weekly sensor alignment check and monthly rotating component lubrication optimise performance.
Q: How quickly can I swap products?
A: Digital memory presets and tool-free changes enable product changeovers in less than five minutes, minimising production downtime.
Q: What can I expect in accuracy on extended production runs?
A: The ±1mm precision tolerance is maintained over millions of cycles thanks to servo controlled tensioning and vibration dampened structure, minimising mechanical drift.
